Вставка реле перемикача S3000

System 3000 relay switching insert – Switching of lighting and single-phase motors. – Control of electric underfloor heating and thermal servos in combination with a room temperature controller top unit. – Adaptive zero-point switch-off – Connecting auxiliary units is possible. – The load is switched off automatically. Delay times can be set to one of five levels, cannot be re-triggered. – Test run for function testing. – Operation with neutral conductor connection. Combination with RF operating top unit, 1-gang / 2-gang for KNX: – Switching actuator channel, 1-gang or heating actuator, 1-gang – Sensor channel, 1-gang or 2-gang. – Local control of System 3000 insert possible. – Wireless control of other devices for KNX possible as a sensor. – Temperature detection. – {b}Insert function selection for switching:{b} NO/NC operation, staircase function with switch-off pre-warning, scene function (16 scenes), blocking function, time delays. Auxiliary input can be used as an additional operating point for the System 3000 insert or for wireless control of other devices for KNX as a sensor. – {b}Insert function selection for room temperature controller:{b}Control of 230 V servos, heating mode, cooling mode, heating and cooling mode, switchover to heating or cooling mode via communication object or auxiliary input. PWM and 2-point controller, absolute and relative setpoint setting, heating requirement control incl. cascading, valve protection function. Cyclical monitoring of the floor temperature, service mode for valve output, frost protection function (automatic or via communication object), temperature sensor calibration, boost function, summer and winter compensation, scene function (16 scenes). If the ambient temperature is higher than 35 °C, the connected load must be reduced.
