89643501 Abox 250/350 KLS-25²/35²
Код товара: 91777
Ціна за запитом
Terminal block, grey, Rated insulation voltage 690V AC, Rated insulation voltage 690V DC
| Виробник |
|---|
Connecting terminal in accordance with DIN EN 60998 (VDE 0613), Ui=690V. For assembly in junction boxes Abox/Abox Pro from 2024 onwards., raised screw terminal block for Abox/Abox Pro 250/350, 5-pole-35mm², In = 125 A, clampable cross-sections per pole: 12 x 10mm², 8 x 16mm², 4 x 25mm², 4 x 35mm² Cu rigid/flexible with wire-end ferrule
Dimensions: 21 x 205 x 48mm
International product number (GTIN): 4013902677368
Universal product code (UPC):
Alternative product number:
Product ID of the manufacturer: 89643501
Manufacturer type description: Abox 250/350 KLS-25²/35²
Ключові слова: Abox 2024, Abox 2024, Abzweigklemme, branch terminal, Klemme, Terminal, Verbindungsklemme, Connecting terminal, Klemmen, Terminals
Special product status:
Classification system: ETIM-9.0
Group reference: EC001284
Посилання
Страница продукта
Link to FAQ
Link to Application example
Link to Download
Link to Technical data sheet
Link to Sales brochure
Link to REACH information
Link to Product page
Dimensioned drawing
Link to Product note
Link to Siemens support portal
Circuit diagram
